D-Link Cat6 UTP 24AWG PVC Cable Roll 305m – Gray (NCB-C6UGRYR-305-24-E)

The D-Link Cat6 UTP 24AWG PVC Cable Roll is a high-performance networking cable designed for reliable data transmission in modern network installations. This 305-meter gray cable roll features 24AWG solid copper conductors and unshielded twisted pair (UTP) construction that supports bandwidth up to 250 MHz. Fully compliant with Category 6 specifications, this cable ensures optimal performance for Gigabit Ethernet, PoE applications, and high-speed data networks. The durable PVC jacket and precise manufacturing make it suitable for commercial installations, office networks, and structured cabling systems requiring consistent performance and long-term reliability.

Product Features

High-performance category 6 specification

Deliver reliable network performance with full Category 6 compliance that supports bandwidth up to 250 MHz. The cable exceeds standard requirements for next-generation data communications, ensuring compatibility with current and future network technologies. This specification guarantees support for Gigabit Ethernet, 10GBASE-T over shorter distances, and other high-speed data applications without performance degradation.

Solid copper conductor construction

Ensure superior conductivity and signal integrity with 24AWG solid bare copper conductors. The solid core design provides better electrical performance over longer distances compared to stranded alternatives, making it ideal for permanent installations in walls, ceilings, and conduit systems. The pure copper material eliminates the signal loss issues associated with copper-clad aluminum alternatives.

Advanced cable design

Maintain signal quality with precise unshielded twisted pair (UTP) construction that reduces crosstalk and electromagnetic interference. The cable features four twisted pairs with consistent twist rates and a central cross separator that minimizes internal interference between pairs. This careful engineering ensures stable performance even in environments with multiple cable runs in close proximity.

Durable pvc jacket protection

Protect your cable investment with a tough gray PVC jacket rated for vertical flame resistance (UL VW-1/CSA FT-1). The jacket material provides excellent durability against physical stress, environmental factors, and installation handling. The gray color offers professional appearance and easy identification in various installation environments.

Comprehensive application support

Support diverse network applications including 10/100/1000BASE-T Ethernet, 10GBASE-T over limited distances, Power over Ethernet (PoE), voice communications, and video transmission. The cable’s performance characteristics make it suitable for mixed-use environments where a single cable infrastructure must support data, voice, and power delivery requirements.

Standard length efficiency

Install networks efficiently with the standard 305-meter (1000-foot) box length that minimizes splices and connections in long cable runs. The box length is optimized for commercial installations, reducing waste and ensuring consistent performance throughout large-scale deployments. The cable spool is designed for smooth payout and easy handling during installation.

Product Specifications

• Manufacturer: D-Link
• Model: NCB-C6UGRYR-305-24-E
• Cable type: Category 6 UTP
• Cable length: 305 meters
• Color: Gray
• Conductor type: Solid core
• Conductor material: Bare copper
• Conductor size: 24 AWG
• Conductor diameter: 0.574 mm ± 0.007 mm
• Conductor construction: Solid core
• Insulation material: High-density polyethylene (HD-PE)
• Insulation thickness: 0.22 mm average
• Insulation diameter: 1.00 mm ± 0.05 mm
• Pair count: 4 twisted pairs
• Shielding: UTP (unshielded twisted pair)
• Separation: Central cross divider
• Jacket material: PVC UL94V-0
• Jacket hardness: 90A ± 2A (Shore)
• Cable diameter: 6.0 mm ± 0.2 mm
• Jacket thickness: 0.60 mm average
• Category rating: Category 6
• Bandwidth: 250 MHz
• Impedance: 100 ohms ± 15%
• Temperature rating: 75°C minimum
• Flame rating: VW-1 (UL), FT-1 (CSA)
• Safety standard: UL94V-0 compliant
• Smoke characteristics: Low smoke zero halogen (LSZH) options available
• Ethernet standards: 10BASE-T, 100BASE-TX, 1000BASE-T, 10GBASE-T
• Additional support: ATM, ISDN, T1, VoIP, broadband video
• Power delivery: Power over Ethernet (PoE) compatible
